ROUTER DRAYTEK VIGOR 2620LN
Typically delivered within 3 to 5 business days.
ROUTER DRAYTEK VIGOR 2620LN LTE – Conexão confiável à Internet para pequenos escritórios
O ROUTER DRAYTEK VIGOR 2620LN LTE é um modem roteador VDSL2/ADSL2+ com 2 slots de cartão SIM integrados (1 SIM online por vez) para failover 4G/LTE. Ele é equipado com 2 portas LAN Gigabit Ethernet, uma das quais pode ser alternada para uma interface WAN de backup adicional. É a solução para pequenas e médias empresas minimizarem o tempo de inatividade da Internet.
A série Vigor2620 LTE é um roteador versátil para uma rede empresarial com cerca de 30 hosts. Ele pode ter dois túneis VPN simultâneos para conectar-se aos escritórios principais ou fornecer acesso remoto para administradores de rede. Também oferece flexibilidade para gerenciamento de rede, incluindo encaminhamento de porta, firewall SPI, filtragem de conteúdo, gerenciamento de largura de banda, QoS e muito mais. A série inclui modelos com Wi-Fi 11n integrado.
Interface |
|
| Fixed WAN Port | 1x RJ-11 for VDSL2 or ADSL2/2+ |
| LAN/WAN Switchable Port | 1x GbE RJ-45 (LAN P2 can be Configured as Ethernet WAN) |
| Fixed LAN Port | 1x GbE RJ-45 |
| SIM Slot | 2x Standard-Sized |
| LTE Antenna | 2x External Dipole Gain: 3 dBi |
| Wi-Fi Antenna | 2x Internal PIFA Gain: 2 dBi for 2.4GHz (wireless model) |
| 2.4G WLAN | 802.11n 2×2 MIMO 300Mbps (n model) |
Performance |
|
| Max. Throughput on VDSL | 95 Mbps |
| Max. NAT Throughput | 300 Mbps |
| IPsec VPN Performance | 55 Mbps (AES 256 bits) |
| SSL VPN Performance | 25 Mbps |
| Max. Number of NAT Sessions | 30,000 |
| Max. Concurrent VPN Tunnels | 2 |
| Max. Concurrent OpenVPN + SSL VPN | 2 |
VDSL/ADSL |
|
| VDSL Standards | ITU-T G.993.1 (VDSL), G.997.1, G.993.2 (VDSL2) |
| VDSL2 Profile | 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a |
| VDSL Band Plan | 997 |
| G.Vectoring | |
| ADSL Standards | ANSI T1.413, ITU-T G.992.1(G.dmt), G.992.2 (G.lite) |
| ADSL2 Standards | ITU-T G.992.3, G.992.3 Annex M/J |
| ADSL2+ Standards | ITU-T G.992.5, G.992.5 Annex M/J |
LTE |
|
| LTE Category | 4 |
| Max. Data Rate | 150 Mbps downlink, 50 Mbps uplink |
| FDD Band | 1 (2100MHz), 3 (1800MHz), 7 (2600MHz), 8 (900MHz), 20 (800MHz) |
| WCDMA (3G) Band | 1, 8 |
| For other band availability, please contact your local DrayTek distributor or us | |
Internet Connection |
|
| IPv4 | PPPoE, DHCP, Static IP |
| IPv6 | PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| LTE WAN Bridge | DHCP Client |
| Multi-VLAN/PVC | |
| WAN Failover | |
| Connection Detection | ARP, Ping |
| Dynamic DNS | |
| DrayDDNS | |
| WAN Budget | |
LAN Management |
|
| VLAN | 802.1q Tag-based, Port-based |
| Max. Number of VLAN | 8 |
| Number of LAN Subnet | 2 |
| DHCP Server | Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
Networking |
|
| Routing | IPv4 Static Routing, IPv6 Static Routing, RIPv2 |
| Multicast | IGMP Proxy, IGMP Snooping & Fast Leave |
VPN |
|
| LAN-to-LAN | |
| Teleworker-to-LAN | |
| Protocols | PPTP, L2TP, IPsec, L2TP over IPsec, SSL, IKEv2, IPsec XAuth, OpenVPN(Host to LAN) |
| User Authentication | Local, RADIUS, mOTP |
| IKE Authentication | Pre-Shared Key, X.509 |
| IPsec Authentication | SHA-1, SHA-256, MD5 |
| NAT-Traversal (NAT-T) | |
| DrayTek VPN Matcher | |
Firewall & Content Filtering |
|
| NAT | Port Redirection, Open Ports, DMZ Host, UPnP |
| ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323 |
| VPN Pass-Through | PPTP, L2TP, IPsec |
| IP-based Firewall Policy | |
| Content Filtering | Application, URL, Web Features, Web Category*, DNS Keyword (*: subscription required) |
| DoS Attack Defense | |
| Spoofing Defense | |
Bandwidth Management |
|
| IP-based Bandwidth Limit | |
| IP-based Session Limit | |
| QoS (Quality of Service) | TOS, DSCP, 802.1p, IP Address, Port |
Wireless LAN (n model) |
|
| Number of SSID | 4 per radio band |
| Security Mode | WEP, WPA, WPA2, Mixed(WPA+WPA2) |
| Authentication | Pre-Shared Key, 802.1X |
| WPS | PIN, PBC |
| WDS | Bridge, Repeater |
| Access Control | Access List, Client Isolation, Hide SSID, Wi-Fi Scheduling |
| WMM | |
Management |
|
| Local Service | HTTP, HTTPS, Telnet, SSH, TR-069, SMS Sending & Recieving |
| Config File Export & Import | |
| Firmware Upgrade | TFTP, HTTP, TR-069 |
| Access Control | Access List, Brute Force Protection |
| Notification Alert | SMS, E-mail |
| SNMP | v2, v2c, v3 |
| Syslog | |
| Central AP Management | 2 VigorAP |
| Managed by VigorACS | |
Mais informações:
https://www.draytek.com/products/vigor2620-lte/
